品牌：蓝江/LAND
材料：外壳为黄铜镀镍，密封件为改性橡胶
防水：IP66/IP68
阻燃：UL94V-2
温度：-40°C～105°C，短时可达120°C
性能：内外丝接管式设计，外螺纹连接设备，内螺纹连接各类管件
蓝江产品型号 | 外螺纹 | 内螺纹 | 电缆范围 | 螺纹长度 | 扳手尺寸 | 包装 |
Product model | M-thread | F-thread | Cable range | Thread length | Wrench Size | packaging |
PN. | External | internal | φ mm | GL mm | nut/cap mm | PCS |
JGEX-M20A-12 | M20×1.5 | M20×1.5 | 7～12 | 12 | 24/24 | 20 |
JGEX-M20A-11 | M20×1.5 | M20×1.5 | 6～10.5 | 12 | 24/24 | 20 |
JGEX-M20A-09 | M20×1.5 | M20×1.5 | 5～9 | 12 | 24/24 | 20 |
JGEX-M25A-18 | M25×1.5 | M25×1.5 | 13～18 | 12 | 32/32 | 20 |
JGEX-M25A-16 | M25×1.5 | M25×1.5 | 11～16 | 12 | 32/32 | 20 |
JGEX-M25A-14 | M25×1.5 | M25×1.5 | 8～14 | 12 | 32/32 | 20 |
JGEX-M25A-10 | M25×1.5 | M25×1.5 | 6～10 | 12 | 32/32 | 20 |
JGEX-M32A-25 | M32×1.5 | M32×1.5 | 18～25 | 12.5 | 40/40 | 20 |
JGEX-M32A-22 | M32×1.5 | M32×1.5 | 16～22 | 12.5 | 40/40 | 20 |
JGEX-G1/2A-12 | G1/2 | G1/2 | 7～12 | 12 | 24/24 | 20 |
JGEX-G1/2A-11 | G1/2 | G1/2 | 6～10.5 | 12 | 24/24 | 20 |
JGEX-G1/2A-09 | G1/2 | G1/2 | 5～9 | 12 | 24/24 | 20 |
JGEX-G3/4A-18 | G3/4 | G3/4 | 13～18 | 12 | 32/32 | 20 |
JGEX-G3/4A-16 | G3/4 | G3/4 | 11～16 | 12 | 32/32 | 20 |
JGEX-G3/4A-14 | G3/4 | G3/4 | 8～14 | 12 | 32/32 | 20 |
JGEX-G3/4A-10 | G3/4 | G3/4 | 6～10 | 12 | 32/32 | 20 |
JGEX-G1A-25 | G1 | G1 | 18～25 | 12.5 | 40/40 | 20 |
JGEX-G1A-22 | G1 | G1 | 16～22 | 12.5 | 40/40 | 20 |
JGEX-NPT1/2A-12 | G1/2 | G1/2 | 7～12 | 12 | 24/24 | 20 |
JGEX-NPT1/2A-11 | G1/2 | G1/2 | 6～10.5 | 12 | 24/24 | 20 |
JGEX-NPT1/2A-09 | G1/2 | G1/2 | 5～9 | 12 | 24/24 | 20 |
JGEX-NPT3/4A-18 | G3/4 | G3/4 | 13～18 | 12 | 32/32 | 20 |
JGEX-NPT3/4A-16 | G3/4 | G3/4 | 11～16 | 12 | 32/32 | 20 |
JGEX-NPT3/4A-14 | G3/4 | G3/4 | 8～14 | 12 | 32/32 | 20 |
JGEX-NPT3/4A-10 | G3/4 | G3/4 | 6～10 | 12 | 32/32 | 20 |
JGEX-NPT1A-22 | G1 | G1 | 16～22 | 12.5 | 40/40 | 20 |
JGEX-NPT1A-25 | G1 | G1 | 18～25 | 12.5 | 40/40 | 20 |
