品牌：蓝江/LAND
材料：外壳黄铜镀镍，密封圈为改性橡胶
检测：CE，IP68，UL94V-2
防爆：Ex eb IIC Gb/Ex tb IIIC Db
温度：-40°C～105°C，短时可达120°C
性能：产品外形美观，螺纹精密，加厚防爆设计，适用于各类增安粉尘防爆电气
产品参数表/M
蓝江产品型号 | 螺纹规格 | 建议开孔 | 电缆范围 | 螺纹长度 | 扳手尺寸 | 包装 |
Product model | Thread size | Hole size | Cable range | Thread length | Wrench Size | packaging |
PN. | Metric | AG φ mm | φ mm | GL mm | nut/cap mm | PCS |
MG12A-08 | M12×1.5 | 12 | 4～8 | 8 | 17/17 | 50 |
MG12A-05 | M12×1.5 | 12 | 3～5 | 8 | 17/17 | 50 |
MG16AS-08 | M16×1.5 | 16 | 4～8 | 8 | 18/18 | 50 |
MG16AS-05 | M16×1.5 | 16 | 3～5 | 8 | 18/18 | 50 |
MG16A-10 | M16×1.5 | 16 | 6～10 | 9 | 22/22 | 50 |
MG16A-07 | M16×1.5 | 16 | 4～7 | 9 | 22/22 | 50 |
MG16A-05 | M16×1.5 | 16 | 3～5 | 9 | 22/22 | 50 |
MG16A-04 | M16×1.5 | 16 | 2～4 | 9 | 22/22 | 50 |
MG18A-14 | M18×1.5 | 18 | 8～14 | 9.5 | 26/26 | 50 |
MG18A-10 | M18×1.5 | 18 | 6～10 | 9 | 22/22 | 50 |
MG18A-07 | M18×1.5 | 18 | 4～7 | 9 | 22/22 | 50 |
MG20AS-12 | M20×1.5 | 20 | 7～12 | 10 | 24/24 | 50 |
MG20AS-11 | M20×1.5 | 20 | 6～11 | 10 | 24/24 | 50 |
MG20AS-09 | M20×1.5 | 20 | 5～9 | 10 | 24/24 | 50 |
MG20A-14 | M20×1.5 | 20 | 8～14 | 10 | 26/26 | 50 |
MG20A-12 | M20×1.5 | 20 | 6～11 | 10 | 26/26 | 50 |
MG20A-09 | M20×1.5 | 20 | 5～9 | 10 | 26/26 | 50 |
MG20A-06 | M20×1.5 | 20 | 3～6.5 | 10 | 26/26 | 50 |
MG25A-18 | M25×1.5 | 25 | 13～18 | 12 | 32/32 | 50 |
MG25A-16 | M25×1.5 | 25 | 11～16 | 12 | 32/32 | 50 |
MG25A-14 | M25×1.5 | 25 | 8～14 | 12 | 32/32 | 50 |
MG25A-10 | M25×1.5 | 25 | 6～10 | 12 | 32/32 | 50 |
MG25A-08 | M25×1.5 | 25 | 4～8 | 12 | 32/32 | 50 |
MG25A-06 | M25×1.5 | 25 | 3～6 | 12 | 32/32 | 50 |
MG32A-25 | M32×1.5 | 32 | 18～25 | 12.5 | 40/40 | 20 |
MG32A-22 | M32×1.5 | 32 | 16～22 | 12.5 | 40/40 | 20 |
MG40A-30 | M40×1.5 | 40 | 24～30 | 15 | 50/50 | 10 |
MG40A-25 | M40×1.5 | 40 | 18～25 | 15 | 50/50 | 10 |
MG50A-40 | M50×1.5 | 50 | 33～40 | 15 | 59/59 | 10 |
MG50A-33 | M50×1.5 | 50 | 25～33 | 15 | 59/59 | 10 |
MG63A-51 | M63×1.5 | 63 | 46～51 | 15 | 73/73 | 10 |
MG63A-46 | M63×1.5 | 63 | 40～46 | 15 | 73/73 | 10 |
MG63A-35 | M63×1.5 | 63 | 28～35 | 15 | 73/73 | 10 |
产品参数表/PG
蓝江产品型号 | 螺纹规格 | 建议开孔 | 电缆范围 | 螺纹长度 | 扳手尺寸 | 包装 |
Product model | Thread size | Hole size | Cable range | Thread length | Wrench Size | packaging |
PN. | Metric | AG φ mm | φ mm | GL mm | nut/cap mm | PCS |
PG7A-08 | PG7 | 12.5 | 4～8 | 8 | 17/17 | 50 |
PG7A-05 | PG7 | 12.5 | 3～5 | 8 | 17/17 | 50 |
PG9A-08 | PG9 | 15.2 | 4～8 | 8 | 18/18 | 50 |
PG9A-05 | PG9 | 15.2 | 3～5 | 8 | 18/18 | 50 |
PG11A-10 | PG11 | 18.6 | 6～10 | 9 | 22/22 | 50 |
PG11A-07 | PG11 | 18.6 | 4～7 | 9 | 22/22 | 50 |
PG11A-05 | PG11 | 18.6 | 3～5 | 9 | 22/22 | 50 |
PG11A-04 | PG11 | 18.6 | 2～4 | 9 | 22/22 | 50 |
PG13.5A-12 | PG13.5 | 20.4 | 7～12 | 9.5 | 24/24 | 50 |
PG13.5A-11 | PG13.5 | 20.4 | 6.5～10.5 | 9.5 | 24/24 | 50 |
PG13.5A-09 | PG13.5 | 20.4 | 5～9 | 9.5 | 24/24 | 50 |
PG16A-14 | PG16 | 22.5 | 8～14 | 10 | 26/26 | 50 |
PG16A-12 | PG16 | 22.5 | 6～12 | 10 | 26/26 | 50 |
PG16A-06 | PG16 | 22.5 | 3～6.5 | 10 | 26/26 | 50 |
PG21A-18 | PG21 | 28.3 | 13～18 | 12 | 32/32 | 50 |
PG21A-16 | PG21 | 28.3 | 11～16 | 12 | 32/32 | 50 |
PG21A-14 | PG21 | 28.3 | 8～14 | 12 | 32/32 | 50 |
PG21A-10 | PG21 | 28.3 | 6～10 | 12 | 32/32 | 50 |
PG21A-09 | PG21 | 28.3 | 6～9 | 12 | 32/32 | 50 |
PG21A-08 | PG21 | 28.3 | 4～8 | 12 | 32/32 | 50 |
PG21A-06 | PG21 | 28.3 | 3～6.5 | 12 | 32/32 | 50 |
PG29A-25 | PG29 | 37 | 18～25 | 12.5 | 40/40 | 20 |
PG29A-22 | PG29 | 37 | 16～22 | 12.5 | 40/40 | 20 |
PG36A-30 | PG36 | 47 | 24～30 | 15 | 50/50 | 10 |
PG36A-25 | PG36 | 47 | 18～25 | 15 | 50/50 | 10 |
PG42A-40 | PG42 | 54 | 33～40 | 15 | 59/59 | 10 |
PG42A-33 | PG42 | 54 | 25～33 | 15 | 59/59 | 10 |
PG48A-51 | PG48 | 59.3 | 44～51 | 15 | 73/73 | 10 |
PG48A-46 | PG48 | 59.3 | 39～46 | 15 | 73/73 | 10 |
PG48A-35 | PG48 | 59.3 | 28～35 | 15 | 73/73 | 10 |
产品参数表/G
蓝江产品型号 | 螺纹规格 | 建议开孔 | 电缆范围 | 螺纹长度 | 扳手尺寸 | 包装 |
Product model | Thread size | Hole size | Cable range | Thread length | Wrench Size | packaging |
PN. | Metric | AG φ mm | φ mm | GL mm | nut/cap mm | PCS |
G1/4A-08 | G1/4 | 13.15 | 4～8 | 8 | 17/17 | 50 |
G1/4A-05 | G1/4 | 13.15 | 3～5 | 8 | 17/17 | 50 |
G3/8A-10 | G3/8 | 16.66 | 6～10 | 9 | 22/22 | 50 |
G3/8A-07 | G3/8 | 16.66 | 4～7 | 9 | 22/22 | 50 |
G3/8A-05 | G3/8 | 16.66 | 3～5 | 9 | 22/22 | 50 |
G3/8A-04 | G3/8 | 16.66 | 2～4 | 9 | 22/22 | 50 |
G1/2A-12 | G1/2 | 20.95 | 7～12 | 9.5 | 24/24 | 50 |
G1/2A-11 | G1/2 | 20.95 | 6～10.5 | 9.5 | 24/24 | 50 |
G1/2A-09 | G1/2 | 20.95 | 5～9 | 9.5 | 24/24 | 50 |
G1/2A-14 | G1/2 | 20.95 | 8～14 | 10 | 26/26 | 50 |
G1/2A-06 | G1/2 | 20.95 | 3～6 | 10 | 26/26 | 50 |
G3/4A-18 | G3/4 | 26.66 | 13～18 | 12 | 32/32 | 50 |
G3/4A-16 | G3/4 | 26.66 | 11～16 | 12 | 32/32 | 50 |
G3/4A-14 | G3/4 | 26.66 | 8～14 | 12 | 32/32 | 50 |
G3/4A-10 | G3/4 | 26.66 | 6～10 | 12 | 32/32 | 50 |
G3/4A-09 | G3/4 | 26.66 | 6～9 | 12 | 32/32 | 50 |
G3/4A-08 | G3/4 | 26.66 | 4～8 | 12 | 32/32 | 50 |
G3/4A-06 | G3/4 | 26.66 | 3～6.5 | 12 | 32/32 | 50 |
G1A-25 | G1 | 33.2 | 18～25 | 12.5 | 40/40 | 20 |
G1A-22 | G1 | 33.2 | 16～22 | 12.5 | 40/40 | 20 |
G1-1/4A-30 | G1-1/4 | 41.9 | 24～30 | 15 | 50/50 | 10 |
G1-1/4A-25 | G1-1/4 | 41.9 | 18～25 | 15 | 50/50 | 10 |
G1-1/2A-40 | G1-1/2 | 47.8 | 33～40 | 15 | 59/59 | 10 |
G1-1/2A-33 | G1-1/2 | 47.8 | 25～33 | 15 | 59/59 | 10 |
G2A-51 | G2 | 59.6 | 44～51 | 15 | 68/68 | 10 |
G2A-46 | G2 | 59.6 | 39～46 | 15 | 68/68 | 10 |
G2A-35 | G2 | 59.6 | 28～35 | 15 | 68/68 | 10 |
产品参数表/NPT
蓝江产品型号 | 螺纹规格 | 建议开孔 | 电缆范围 | 螺纹长度 | 扳手尺寸 | 包装 |
Product model | Thread size | Hole size | Cable range | Thread length | Wrench Size | packaging |
PN. | Metric | AG φ mm | φ mm | GL mm | nut/cap mm | PCS |
NPT1/4A-08 | NPT1/4 | 13.15 | 4～8 | 8 | 17 | 50 |
NPT1/4A-05 | NPT1/4 | 13.15 | 3～5 | 8 | 17 | 50 |
NPT3/8A-10 | NPT3/8 | 16.66 | 6～10 | 9 | 22 | 50 |
NPT3/8A-07 | NPT3/8 | 16.66 | 4～7 | 9 | 22 | 50 |
NPT3/8A-05 | NPT3/8 | 16.66 | 3～5 | 9 | 22 | 50 |
NPT3/8A-04 | NPT3/8 | 16.66 | 2～4 | 9 | 22 | 50 |
NPT1/2A-12 | NPT1/2 | 20.95 | 7～12 | 9.5 | 24 | 50 |
NPT1/2A-11 | NPT1/2 | 20.95 | 6～10.5 | 9.5 | 24 | 50 |
NPT1/2A-09 | NPT1/2 | 20.95 | 5～9 | 9.5 | 24 | 50 |
NPT1/2A-14 | NPT1/2 | 20.95 | 8～14 | 10 | 26 | 50 |
NPT1/2A-06 | NPT1/2 | 20.95 | 3～6 | 10 | 26 | 50 |
NPT3/4A-18 | NPT3/4 | 26.66 | 13～18 | 12 | 32 | 50 |
NPT3/4A-16 | NPT3/4 | 26.66 | 11～16 | 12 | 32 | 50 |
NPT3/4A-14 | NPT3/4 | 26.66 | 8～14 | 12 | 32 | 50 |
NPT3/4A-10 | NPT3/4 | 26.66 | 6～10 | 12 | 32 | 50 |
NPT3/4A-09 | NPT3/4 | 26.66 | 6～9 | 12 | 32 | 50 |
NPT3/4A-08 | NPT3/4 | 26.66 | 4～8 | 12 | 32 | 50 |
NPT3/4A-06 | NPT3/4 | 26.66 | 3～6.5 | 12 | 32 | 50 |
NPT1A-25 | NPT1 | 33.2 | 18～25 | 12.5 | 40 | 20 |
NPT1A-22 | NPT1 | 33.2 | 16～22 | 12.5 | 40 | 20 |
NPT1-1/4A-30 | NPT1-1/4 | 41.9 | 24～30 | 15 | 50 | 10 |
NPT1-1/4A-25 | NPT1-1/4 | 41.9 | 18～25 | 15 | 50 | 10 |
NPT1-1/2A-40 | NPT1-1/2 | 47.8 | 33～40 | 15 | 59 | 10 |
NPT1-1/2A-33 | NPT1-1/2 | 47.8 | 25～33 | 15 | 59 | 10 |
NPT2A-51 | NPT2 | 59.6 | 44～51 | 15 | 68 | 10 |
NPT2A-46 | NPT2 | 59.6 | 39～46 | 15 | 68 | 10 |
NPT2A-35 | NPT2 | 59.6 | 28～35 | 15 | 68 | 10 |
