品牌：蓝江/LAND
材料：外壳为黄铜镀镍，密封件为改性橡胶
防水：IP68
阻燃：UL94V-2
温度：-40°C～105°C，短时可达120°C
性能：外形美观，90度标准弯角设计，用于设备电缆弯曲引导保护
蓝江产品型号 | 螺纹规格 | 建议开孔 | 电缆范围 | 螺纹长度 | 扳手尺寸 | 包装 |
Product model | M Thread | Hole size | Cable range | Thread length | Wrench Size | packaging |
PN. | M | AG φ mm | φ mm | GL mm | nut/cap mm | PCS |
MG12B-E-06 | M12×1.5 | 12 | 3～6.5 | 6 | 14/14 | 20 |
MG12B-E-08 | M12×1.5 | 14 | 4～8 | 6 | 14/16 | 20 |
MG14B-E-08 | M14×1.5 | 14 | 4～8 | 7 | 17/17 | 20 |
MG16B-E-08 | M16×1.5 | 16 | 4～8 | 7 | 17/18 | 20 |
MG16B-E-10 | M16×1.5 | 16 | 5～10 | 7 | 20/20 | 20 |
MG18B-E-10 | M18×1.5 | 18 | 5～10 | 7 | 20/20 | 20 |
MG20B-E-12 | M20×1.5 | 20 | 6～12 | 8 | 22/22 | 20 |
MG25B-E-18 | M25×1.5 | 25 | 13～18 | 8 | 30/30 | 20 |
MG32B-E-25 | M32×1.5 | 32 | 18～25 | 9 | 40/40 | 20 |
MG40B-E-30 | M40×1.5 | 40 | 22～30 | 10 | 45/45 | 20 |
MG50B-E-32 | M50×1.5 | 50 | 24～32 | 10 | 57/55 | 20 |
MG63B-E-44 | M63×1.5 | 63 | 37～44 | 12 | 64/68 | 20 |
G1/4B-E-06 | G1/4 | 13.15 | 3～6.5 | 6 | 14/16 | 20 |
G3/8B-E-10 | G3/8 | 16.65 | 6～10 | 7 | 17/18 | 20 |
G1/2B-E-12 | G1/2 | 20.95 | 6～12 | 8 | 22/22 | 20 |
G3/4B-E-18 | G3/4 | 26.44 | 13～18 | 8 | 30/30 | 20 |
G1B-E-22 | G1 | 33.24 | 16～22 | 9 | 34/36 | 20 |
G1-1/4B-E-30 | G1-1/4 | 41.91 | 23～30 | 10 | 45/45 | 20 |
G1-1/2B-E-32 | G1-1/2 | 47.80 | 25～32 | 10 | 50/52 | 20 |
G2B-E-44 | G2 | 59.61 | 37～44 | 12 | 64/64 | 20 |
