品牌：蓝江/LAND
材料：外壳为304（可选316或316L），密封件为改性橡胶
防水：IP66
阻燃：UL94V-2
温度：-40°C～105°C，短时可达120°C
环保：ROHS四项
防爆：Ex db IIC Gb/Ex eb IIC Gb/Ex tb IIIC Db
性能：单层加长密封圈设计，外形美观，螺纹精密，具备耐腐蚀，耐高温，防爆等特性
蓝江产品型号 | 螺纹规格 | 建议开孔 | 电缆范围 | 螺纹长度 | 扳手尺寸 | 包装 |
Product model | Thread size | Hole size | Cable range | Thread length | Wrench Size | packaging |
PN. | Metric | AG φ mm | φ mm | GL mm | nut/cap mm | PCS |
Exd1-M20-14-SS | M20×1.5 | 20 | 8～14 | 15 | 26 | 20 |
Exd1-M25-16-SS | M25×1.5 | 25 | 8～16 | 15 | 30 | 20 |
Exd1-M25-20-SS | M25×1.5 | 25 | 10～20 | 15 | 38 | 20 |
Exd1-M32-20-SS | M32×1.5 | 32 | 10～20 | 18 | 38 | 10 |
Exd1-M32-25-SS | M32×1.5 | 32 | 10～25 | 18 | 46 | 10 |
Exd1-M40-25-SS | M40×1.5 | 40 | 10～25 | 18 | 46 | 5 |
Exd1-M40-32-SS | M40×1.5 | 40 | 14～32 | 18 | 50 | 5 |
Exd1-M50-32-SS | M50×1.5 | 50 | 14～32 | 18 | 50 | 5 |
Exd1-M50-41-SS | M50×1.5 | 50 | 17～41 | 18 | 62 | 5 |
Exd1-M63-41-SS | M63×1.5 | 63 | 17～41 | 18 | 62 | 1 |
Exd1-G1/2-14-SS | G1/2 | 20.95 | 8～14 | 15 | 26 | 20 |
Exd1-G3/4-16-SS | G3/4 | 26.44 | 8～16 | 15 | 30 | 20 |
Exd1-G3/4-20-SS | G3/4 | 26.44 | 10～20 | 15 | 38 | 20 |
Exd1-G1-20-SS | G1 | 33.2 | 10～20 | 18 | 38 | 10 |
Exd1-G1-25-SS | G1 | 33.1 | 10～25 | 18 | 46 | 10 |
Exd1-G1-1/4-25-SS | G1-1/4 | 41.9 | 10～25 | 18 | 46 | 5 |
Exd1-G1-1/4-32-SS | G1-1/4 | 41.9 | 14～32 | 18 | 50 | 5 |
Exd1-G1-1/2-32-SS | G1-1/2 | 47.8 | 14～32 | 18 | 50 | 5 |
Exd1-G1-1/2-41-SS | G1-1/2 | 47.8 | 17～41 | 18 | 62 | 5 |
Exd1-G2-41-SS | G2 | 59.6 | 17～41 | 18 | 62 | 1 |
Exd1-NPT1/2-14-SS | NPT1/2 | 20.95 | 8～14 | 15 | 26 | 20 |
Exd1-NPT3/4-16-SS | NPT3/4 | 26.44 | 8～16 | 15 | 30 | 20 |
Exd1-NPT3/4-20-SS | NPT3/4 | 26.44 | 10～20 | 15 | 38 | 20 |
Exd1-NPT1-20-SS | NPT1 | 33.5 | 10～20 | 18 | 38 | 10 |
Exd1-NPT1-25-SS | NPT1 | 33.5 | 10～25 | 18 | 46 | 10 |
Exd1-NPT1-1/4-25-SS | NPT1-1/4 | 42 | 10～25 | 18 | 46 | 5 |
Exd1-NPT1-1/4-32-SS | NPT1-1/4 | 42 | 14～32 | 18 | 50 | 5 |
Exd1-NPT1-1/2-32-SS | NPT1-1/2 | 48 | 14～32 | 18 | 50 | 5 |
Exd1-NPT1-1/2-41-SS | NPT1-1/2 | 48 | 17～41 | 18 | 62 | 5 |
Exd1-NPT2-41-SS | NPT2 | 60 | 17～41 | 18 | 62 | 1 |
